2000kgs Coil Loading Flat Decoiler for sale for High Speed Press Punch

2000kgs Coil Loading Flat Decoiler for sale for High Speed Press Punch

2000kgs Coil Loading Flat Decoiler for sale for High Speed Press Punch
2000kgs Coil Loading Flat Decoiler for sale for High Speed Press Punch2000kgs Coil Loading Flat Decoiler for sale for High Speed Press Punch2000kgs Coil Loading Flat Decoiler for sale for High Speed Press Punch2000kgs Coil Loading Flat Decoiler for sale for High Speed Press Punch
CategoriesFlat Decoiler
BrandFANTY Steel Coil Handling Equipment Manufacturer
ModelFU Series Coil Loading Flat Decoiler
CatagoryDecoiler Machine
BrandFANTY
ModelFU series
Machine ColorStandard white (other colors are available)
FOB PortShenzhen
FOB portShenzhen
Update TimeMay 18,2024
Detail Information
The 2000kg coil loading flat decoiler, specifically designed for high-speed punch press machines. More than just a decoiler, it serves as a versatile solution for efficient and high-performance production.
Employing advanced design and technology, this decoiler aims to achieve rapid and stable coil feeding to meet the demands of high-speed punch press operations. Its robust construction ensures durability under high-pressure working environments, guaranteeing prolonged stability. Moreover, our decoiler is equipped with an advanced control system to precisely manage coil uncoiling speed and tension, ensuring stability and accuracy during the punching process.
Whether you're producing automotive parts, household appliance components, or other metal products, our decoiler caters to your diverse needs. It accommodates various coil materials, including steel and aluminum, providing flexible production options.
Beyond just a piece of equipment, we offer comprehensive services. Our after-sales team stands ready to provide support and guidance, ensuring your equipment operates at its best. Whether you're a novice or an experienced manufacturer, we provide the optimal solution for your needs.
If you're in search of a high-performance decoiler, our "2000kgs Coil Loading Flat Decoiler For High Speed Punch Press Machine" is the ideal choice. Contact our sales team for further details and the latest pricing. Let's collaborate to create a brighter future together!
2000kgs Coil Loading Flat Decoiler For High Speed Punch Press Machine
Flat feeder
Material Application
Material thickness:
 0.1mm~1.0mm
Steel strip width:
 0.1mm~150mm
Coil loading weight:
<2500kgs
Material Type:
Steel, Aluminum, Cooper etc
Coil line Type:
High speed
Features of Flat Decoiler

* High efficiency: flat decoiler is highly efficient for steel coil handling and can handle a 0.1mm~1.0mm thickness steel coil, making them suitable for use in heavy-duty industries.
* Accurate feeding: The flat decoiler is designed to provide accurate feeding of materials with a consistent flow rate, which is essential for maintaining process efficiency.
* Adjustable feeding rate: The speed of the decoiler machine can be adjusted to control the rate of material flow, which allows for greater flexibility in the processing of materials.
* Minimal maintenanceflat decoilers are low maintenance machines, with few moving parts that require regular maintenance, making them a cost-effective solution for steel coil handling.

Application of Flat Decoiler
Flat feeder woking with a high speed press and it is the stamping product
Clips
Flat feeder woking with a high speed press and it is the stamping product
Terminals
Flat feeder woking with a high speed press and it is the stamping product
Metal button
Flat feeder woking with a high speed press and it is the stamping product
Eyelets
Specification of Flat Decoiler
Model
FU-500
FU-1000
FU-2000

Max Steel Width(mm)

150
Coil Thickness (mm)
0.1~1.0
Loading Weight(kg)
500
800
1500
Max. Loading Height (mm)
600
Max. Coil O.D.
800
1000
1200
Feeding Speed
24m/min
Motor (HP)
0.5
1.0
2.0
Inverter
Mitsubishi
Mitsubishi
Mitsubishi
